WA-UNO2178-C50HE |
WA-UNO2178-C600E |
WA-UNO2178-E50HE |
WA-UNO2178-E600E |
WA-UNO2178-
T50HE |
WA-UNO2178-
T600E |
| Dashboard |
Cross Browser and Platform |
No |
No |
No |
No |
No |
No |
| Number of Built-in Widget |
No |
No |
No |
No |
No |
No |
| Open Widget Interface |
No |
No |
No |
No |
No |
No |
| Graphics |
Multi-touch Gesture |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| Group Trend Log |
Alarm Groups per SCADA |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Number of data logging |
Number of IO tags license x 2 |
Number of IO tags license x 2 |
Number of IO tags license x 2 |
Number of IO tags license x 2 |
Number of IO tags license x 2 |
Number of IO tags license x 2 |
| I/O Interface |
LAN |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
2 x 10/100/1000Base-T RJ-45 ports (Built-in boot ROM in flash BIOS) |
| USB |
6 x USB 2.0 |
6 x USB 2.0 |
6 x USB 2.0 |
6 x USB 2.0 |
6 x USB 2.0 |
6 x USB 2.0 |
| Open Connectivity |
BACnet Server |
No |
No |
No |
No |
No |
No |
| DDE Server |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| Modbus Server |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| ODBC and SQL Query |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| OPC DA/UA Server |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| Others |
Support IPv6 |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| WebAccess Express |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| Scheduler |
Device Loop Group |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Equipment Group |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Holiday Configuration Group |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Scheduler Reservation Group |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Time Zone Group |
9999 |
9999 |
9999 |
9999 |
9999 |
9999 |
| Web-enabled Integration |
Google Maps and GPS Location Tracking |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
| I/O Interface |
Serial Ports |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
2 x RS-232/485 (COM1-2), 2 x RS-232/422/485 w/ 128kB FIFO (COM A-B), 4 x RS-232/485 from DB25 print port (COM3-6) |
| General |
Certifications |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
Energy Star, CE, FCC Class A, UL, CCC, C-Tick Class A, BSMI |
| Dimensions |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
255 x 152 x 59 mm (10" x 6.0" x 2.3") |
| Enclosure Housing |
Aluminum + SECC |
Aluminum + SECC |
Aluminum + SECC |
Aluminum + SECC |
Aluminum + SECC |
Aluminum + SECC |
| Industrial Grounding |
Isolation between chassis and power ground |
Isolation between chassis and power ground |
Isolation between chassis and power ground |
Isolation between chassis and power ground |
Isolation between chassis and power ground |
Isolation between chassis and power ground |
| Mounting |
DIN-rail, Wallmount, VESA |
DIN-rail, Wallmount, VESA |
DIN-rail, Wallmount, VESA |
DIN-rail, Wallmount, VESA |
DIN-rail, Wallmount, VESA |
DIN-rail, Wallmount, VESA |
| OS Support |
Windows 7 Embedded |
Windows 7 Embedded |
Windows 7 Embedded |
Windows 7 Embedded |
Windows 7 Embedded |
Windows 7 Embedded |
| Power Consumption |
16 W (Typical) |
16 W (Typical) |
16 W (Typical) |
16 W (Typical) |
16 W (Typical) |
16 W (Typical) |
| Power Requirement |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
9 ~ 36 VDC (e.g +24 V @ 1.5 A) (Min. 36 W), ATX |
| System Design |
Fanless design with no internal cabling |
Fanless design with no internal cabling |
Fanless design with no internal cabling |
Fanless design with no internal cabling |
Fanless design with no internal cabling |
Fanless design with no internal cabling |
| System Hardware |
CPU |
Intel Atom D510 Dual Core 1.66 GHz |
Intel Atom D510 Dual Core 1.66 GHz |
Intel Atom D510 Dual Core 1.66 GHz |
Intel Atom D510 Dual Core 1.66 GHz |
Intel Atom D510 Dual Core 1.66 GHz |
Intel Atom D510 Dual Core 1.66 GHz |
| Display |
DB15 VGA connector up to 2048 x 1536 |
DB15 VGA connector up to 2048 x 1536 |
DB15 VGA connector up to 2048 x 1536 |
DB15 VGA connector up to 2048 x 1536 |
DB15 VGA connector up to 2048 x 1536 |
DB15 VGA connector up to 2048 x 1536 |
| Indicators |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
LEDs for Power, CF, LAN (Active, Status), Serial (Tx, Rx) |
| Keyboard/Mouse Ports |
1 x PS/2 |
1 x PS/2 |
1 x PS/2 |
1 x PS/2 |
1 x PS/2 |
1 x PS/2 |
| Memory |
2 GB DDR2 SDRAM built-in |
2 GB DDR2 SDRAM built-in |
2 GB DDR2 SDRAM built-in |
2 GB DDR2 SDRAM built-in |
2 GB DDR2 SDRAM built-in |
2 GB DDR2 SDRAM built-in |
| Storage |
2.5" SATA , 1TB 5400RPM |
2.5" SATA , 1TB 5400RPM |
2.5" SATA , 1TB 5400RPM |
2.5" SATA , 1TB 5400RPM |
2.5" SATA , 1TB 5400RPM |
2.5" SATA , 1TB 5400RPM |
| Processor System |
Watchdog Timer |
1~255 sec (System) |
1~255 sec (System) |
1~255 sec (System) |
1~255 sec (System) |
1~255 sec (System) |
1~255 sec (System) |
| WebAccess Version 8.0 Professional |
Action Logs |
5000 |
5000 |
5000 |
5000 |
5000 |
5000 |
| Alarm Logs |
5000 |
5000 |
5000 |
5000 |
5000 |
5000 |
| Graphics |
Unlimited Number of Graphic Pages, Global Tag Source |
Unlimited Number of Graphic Pages, Global Tag Source |
Unlimited Number of Graphic Pages, Global Tag Source |
Unlimited Number of Graphic Pages, Global Tag Source |
Unlimited Number of Graphic Pages, Global Tag Source |
Unlimited Number of Graphic Pages, Global Tag Source |
| I/O Tag Number |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
| Internal Tag Number |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
600/5000 |
| Number of Data Logging |
Number of I/O Tags License x 2 |
Number of I/O Tags License x 2 |
Number of I/O Tags License x 2 |
Number of I/O Tags License x 2 |
Number of I/O Tags License x 2 |
Number of I/O Tags License x 2 |
| Others |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
SCADA Redundancy, TclScript / VBScript / Jscript Language, Data Transfer and Reporting, ODBC and SQL Query, Device Redundancy |
| Web Client |
1024 |
1024 |
1024 |
1024 |
1024 |
1024 |
